Maximum Output Power 1 x 4000W (1), 1 x 3000W (2), 1 x 1500W (4)

Continuous power output (RMS)
1 x 2000W (50Hz/11%THD)
1 x 1500W (50Hz/21%THD)
1 x 750W (20Hz – 240Hz/41%THD)

Load impedance capability 1 – 8

Frequency response 10 – 240 Hz

Distortion < 0.3 %

S/N ratio 85 dB

Bass Boost 40 – 120Hz
0, 6, 9, 12 dB via remote control

LPF 40 – 240Hz (-24dB/Oct)

Subsonic Filter (HPF) 20Hz (-24dB/Oct)

MOSFET output section Ja

Sync Control Ja

RCA terminals Yes (input/output)

Speaker Terminals Block-type

High Voltage Input 200mV – 6.5 V

Input level control 400 mV – 6.5 V

High performance balanced isolator circuit Ja

Max. current consumption (A/4) 67A

Chassis size (W x H x D) 586 x 65 x 282 mm
